Introduction to Pump Types: End Suction Pumps

Posted: 25/03/2020
Category: Wastewater Pump

Sintech is the leading end suction pump manufacturer in India. A cost-effective and efficient pump system, end-suction pumps are used in a broad range of applications. Here at Sintech, we offer both readymade pumps as well as custom-engineered solutions designed to meet your exact specifications.

Here, in this guide, you can find all that you need to know about one of our best-selling pumps – the end suction pump.

What is an end suction pump?


A type of centrifugal pump, end suction pumps are single-stage pumps with only one impeller. The suction pipe along with the casing is present on one end. The other end has the discharge outlet. End suction pumps are highly affordable when compared to other types of centrifugal pumps. Available in a wide range of sizes, materials, and designs, our range of end-suction pumps are designed to handle a variety of liquids. From water at room temperatures to water at high pressure, abrasive slurries to viscous oils and corrosive substances, end-suction pumps are used in a wide range of applications.

How do end suction pumps work?


The majority of end-suction pumps have only one impeller. The liquid to be pumped moves on the impeller vanes, raising the liquid’s velocity. From the impeller, the liquid moves to the casing, where the liquid’s high velocity is converted into high pressure via diffusion.

Generally, most end-suction pumps operate using an AC motor. However, they can also operate using DC electric motors, hydraulic motors, air motors, diesel and petrol engines, and steam turbines.

Types of End Suction Pumps


End suction pumps are of two major types:

Close-coupled end suction pump


In this type, the pump impeller is directly attached to the driver shaft, and there is no separate coupling between the impeller and the shaft. Generally, end suction pumps that are used for water pumping in residential and commercial applications are close-coupled. They are made of iron or plastic and available at affordable costs.

Frame-mounted end suction pump


In this type, the pump has a bearing set and couplings, separating the motor and the pump. End suction pumps that are used for heavy-duty industrial applications are mounted on a bedplate. It has a coupling that separates the motor and the pump.

Heavy-duty end-suction pumps are made using stainless steel or high-grade alloys and plastic. Alternatively, it can also be made using hardened iron for corrosion resistance in applications that displace slurry. Frame-mounted end-suction pumps are used in mineral processing, dredging, mining, and other industrial applications.

End suction pumps used in food processing and chemical industries have open impellers as they pump liquids that contain solids. Pumps that are used for pumping clean water and oil have closed impellers.

For the Best End Suction Pumps in India, Get in Touch with Sintech


At Sintech, leading end suction pump manufacturers in India, we have a wide range of pumps for various applications like residential, commercial and industrial. Our pumps are designed to global standards and are made using high-grade materials that offer long-lasting quality at attractive prices. To know more or to enquire about the latest prices, get in touch with our sales team at sales@sintechpumps.com.
